2.3 Standard Components

The NM-108 BC standard components are shown in Figure 2-3 and listed in Table 2-7.

The ITEM NO. column indicates the number used to identify items in Figure 2-3.

Figure 2-3. STANDARD COMPONENTS

TABLE 2-7. STANDARD COMPONENTS

ITEM

NO.

DESCRIPTION Q-TY

1 NM-108 BC Night Vision Clip-On System - a night vision device equipped with

quick release mount, to be installed on a Picatinny/ Weaver rail. Intended for use in

conjunction with a day scope.

2 Wireless Remote Control Unit – used to operate the NM-108 BC in short-time

activation mode. Ensures quick and silent NM-108 BC activation / deactivation.

Delivered with two CR2016 (3V) batteries installed.

3 Light Suppressor - a rubber cup installed on the NM-108 BC output lens to reduce

light scattering.

4 Operation and Maintenance Manual - provides safety information, equipment

description, mounting procedures, operating instructions, and preventive

maintenance checks and services (including a List of Spare Parts).
